Home / Products / Professional Amplifier / PFA1302 Home Professional Digital Audio Class D 2 Channel OLED Display Power 8Ω 1300W Amplifier Module

PFA1302 Home Professional Digital Audio Class D 2 Channel OLED Display Power 8Ω 1300W Amplifier Module

1. Exquisite design:

Standard 1u height design, sturdy steel shell, lightweight, reliable, innovative and fashionable.

2. Class D: Advanced Class D output circuit

3. PFC: Power factor correction: global operation.(AC:85-265V)

Power load balancing with PFC (power factor correction) technology can enhance the efficiency of power distribution operation

4.Green Audio Amplifier: Legendary green audio power technology can improve efficiency and minimize carbon emissions and power operating costs.

5.SRM (Smart Rail Track Management): Reduce heat consumption and improve efficiency.

New standards for quality and availability

The built-in 4x4 I / O matrix provides highly flexible routing, allowing users to mix and route analog and digital I / O

Simple, plug and play DSP allows any node in the RS485 network to easily route to dBa PC Audio.

Inquire Now Next Product

Model	PFA302	PFA502	PFA802	PFA1002	PFA1302
Outputs Stages
Maximum output power per channel( 8Ω)	300Wx2	500Wx2	800Wx2	1000Wx2	1300Wx2
Maximum output power per channel( 4Ω)	300Wx2	500Wx2	800Wx2	1000Wx2	1300Wx2
Maximum output power per channel( 2Ω)	300Wx2	500Wx2	800Wx2	1000Wx2	1300Wx2
Maximum Bridge output power ( 8Ω )	1000Wx1	1500Wx1	2400Wx1	3000Wx1	4000Wx1
Typical Distortion (8 ohms)	0.02%
Maximum Distortion	<2%
Frequency Response(20-20khz)	+/-1 dB
Noise (20 Hz-20 kHz, 32 dB Gain)	<1mv
Damping Factor (8 ohms)	5000
Output Circuitry	CLASS D
Input Sensitivity	1.5V
Maximum Gain (1.2V setting)	32dB
Maximum Input Level	20dB
AC Power Requirements	85V-265V
Input connector	3-pin XLR, balanced signal input
Output connector	SPEAKON
Limiter set	Peak limiting, RM voltage limiting, RMs current limiting.
Amplifier and load protection	Above/below the specified Ac voltage; Dangerous signal (clippingdistortion, super high frequency, long-term RMS): DC output ; Overtemperature; Short circuit; Mute sound when turning on/off.
Heat dissipation method	Air cooling,fan infinitely variable speed
Nominal Voltage voltage	110-240V 50/60Hz
Fuse	10A
Weight	7.5Kg
Size	W: 483 mm ,D: 268 mm ,H:44 mm
