1. Dual-channel 8Ω 2*1000W,4Ω 2*1800W, suitable for driving dual 18-inch subwoofers and 2+1 full-range line arrays.
2. It is equipped with PFC power factor correction function and can be used within the range of 90-260V.
3. It adopts SRM intelligent audio track management technology, which not only ensures a constant output power under different input voltages, but also intelligently and dynamically adjusts power consumption. In standby mode, it maintains extremely low power consumption, eliminating the need for full-load operation throughout the process. It has a remarkable energy-saving effect and effectively controls the fan temperature, thereby extending the service life of the equipment.
4. With the dedicated DSP software, users can easily debug the system and set parameters on their computers.
5. Equipped with electronic interference certification and circuit hardware protection, it truly ensures stable quality and excellent performance.
| Model | PFA3002+260DA |
| Audio | |
| Power/8Ω EIA 1 KHz 1% THD | 1000Wx2 |
| Power/4Ω EIA 1 KHz 1% THD | 1800Wx2 |
| OUTPUT POWER, BRIDGE MONO MODE | |
| 8Ω EIA 1 KHz 1% THD | 3600Wx1 |
| Typical Distortion | 0.05% |
| Frequency Response (8 ohms) | 20 Hz-20 kHz, ±0.2 dB |
| Damping Factor (8 ohms) | >600 |
| Noise (20 Hz-20 kHz, 32 dB Gain) | <1mv |
| Maximum Gain (1.2V setting) | 36dB |
| DSP | |
| Analog Inputs and output (single ended) | 1 in 2 out |
| Input-to-output latency | 420μs |
| Gain | 36dB |
| Dynamic Range (unity gain) | typ.95dB(A) |
| THD (@ 0dBu, 1kHz, unity gain) | <0.01% |
| Frequency Response | 20 Hz-20 kHz, ±0.5 dB |
| Sample rate | 48kHz |
| Delay | 10ms |
| PEQ (each input and output) | 7 |
| Grouping EQ (each input) | 7 |
| Crossover (each input, LPF and HPF) | 24dB/Oct |
| Crossover (each output, LPF and HPF) | Butterworth,Linkwitz,Bessel 6dB/oct~24dB/oct |
| Limiter attack | 8040 db |
| Limiter release | 23 db |
| S/N | 101dB |
| noiseGata | -100-0dB |
| Size | W: 160 mm , D: 420 mm , H: 65 mm |
