1. Single-channel 8Ω 1000W,4Ω 1200W, suitable for full-range speakers.
2. It is equipped with a variable-speed fan cooling system, effectively controlling the fan temperature and extending the service life of the equipment.
3.LLC switching power supply design, featuring electronic interference certification and circuit hardware protection, truly ensures stable quality and excellent performance.
4. Support product customization.
| Model | PDA601+全频前级 | PDA801+全频前级 | PDA1001+全频前级 |
| Audio | |||
| Power/8Ω EIA 1 kHz 1% THD | 600Wx1 | 600Wx1 | 1000Wx1 |
| Power/4Ω EIA 1 kHz 1% THD | 900Wx1 | 1200Wx1 | 1200Wx1 |
| Typical Distortion | 0.05% | ||
| Frequency Response (8 ohms) | 20 Hz-20 kHz, ±0.2 dB | ||
| Damping Factor (8 ohms) | >600 | ||
| Noise (20 Hz-20 kHz,32 dB Gain) | <1mv | ||
| Maximum Gain (1.2V setting) | 32dB | ||
| DSP | |||
| Analog Inputs and output (single ended) | 1 in 2 out | ||
| Input-to-output latency | NA | ||
| Gain | NA | ||
| Dynamic Range (unity gain) | NA | ||
| THD (@ 0dBu, 1kHz, unity gain) | NA | ||
| Frequency Response | NA | ||
| Sample rate | NA | ||
| Delay | NA | ||
| PEQ (each input and output) | NA | ||
| Grouping EQ (each input) | NA | ||
| Crossover (each input, LPF and HPF) | NA | ||
| Crossover (each output, LPF and HPF) | high cut&low cut | ||
| Limiter attack | NA | ||
| Limiter release | NA | ||
| S/N | NA | ||
| noiseGata | NA | ||
| Fir | NA | ||
| Size | W:360mm,D:142mm,H:65 mm | ||
